The
Bookeye® Color Planetary Scanner has revolutionized the
way that information found in books, newspapers, delicate
over-sized documents, and 3-D objects is captured. Bookeye®
makes scanning in color, black and white, or grayscale
a snap. You can even choose to scan once and create both
color and grayscale or other output combinations
|
|
Features
- 24-bit
Color, Bitonal and Grayscale Output, Separately
or Simultaneously
- Batch
Scanning for Continuous Scanning of Books in Production
Environments
- Alternate
Scan Left and Right Page
- Text
and Photographic Scan Modes
- Photo
Reproduction Mode
- Automatic
White and Color Balance
- Auto-Focus
with 4-inch Depth of Field
- Border
Recognition and Removal
- Minimal
Maintenance Required
- Optional
Foot Pedal
Scan
books, catalogs, newspapers, magazines, large-format
documents, bound, clipped and
stapled material.
Thanks to Bookeye®'s rich functionality, you can achieve
high throughput with bound and stapled documents while
maintaining high image quality.
|
|
| Technical
Specifications
| Resolution |
300
DPI |
| Scan
Modes |
Text,
Photo |
| Compatibility |
Standard
Network Card |
| Dimensions
(H/W/D) |
35
x 27 x 27 inches |
| Weight
(includes packing) |
94
lbs |
| Electrical |
Voltage
Range 120V AC
Frequency Range 50 Hz |
| Power |
Operating
Max: 400 VA |
| Temperature |
25
to 100 F |
| Noise
Level |
45
dbA |
| Relative
Humidity |
20%
- 80% (non-condensing) |
Overview
of Most Common Originals
- Colored
architectural plans
- Colored
wiring diagrams
- Advertisements
and sketches
- Colored
newspapers and periodicals
- Books
- Maps
and drawings
- Atlases
- Ancient
manuscripts
- Surveys
with photos
- Quality
control and documentation
- Graphical
designs
Overview
of Main Functions
- Format
selection up to DIN A2 (17x24”)
- 35
mega-pixel resolution
- 30
bit color depth internally, 24 bit externally
- Automatic
exposure control
- Autofocus
- Automatic
page separation
- Automatic
book-fold correction
- PDF
conversion
- Simple
installation
- Self
calibrating
- User
friendly
Scanning
- Resolution:
200, 300, 400, 600 dpi
- Scantime:
o 2 sec DIN A4 portrait
o 2,2 sec DIN A3 landscape
o 3 sec DIN A2 landscape
- Color
depth (internal/external) 30 bit/24bit
|
|
|
|
|
|
|
|
