Pictured below is the 3 Tier Services Model. During the
Visual Basic Module the
3 Tier Model served to Graphicaly show the sequence of code flow within the
Virtual
Placement Agency Project. This model shows the User Tier, the Business Tier and
the Data Tier our team implemented during coding of this object oriented Project.
