Figure 71

986552 GASOLINE TANK FILLER DOOR
FENDER GUARD

Figure 72

Procedure for Installation of
Gasoline Tank Filler Door Fender Guard
on All Model Passenger Cars.

1. Remove two screws and rubber bumpers
and discard the screws.

2. Attach guard and rubber bumpers using the
screws furnished.

Approximate Flat Rate Time _1 of an hour.

986492 AIR FLOW HEATER

Procedure for Installation of Air Flow Heater
on All Models of Passenger Cars.

Figure 73

IMPORTANT: Clean, bright grounds help to
make the heater more efficient and increases
the R.P.M.'s of the blower, resulting in more
heat.

1. Core and case assembly; remove the rear
portion of right-hand air duct. Remove
screw from top of air valve and add rubber
band seal to valve housing to cover the
screw hole. See view "L." Replace the re
moved portion of the air duct on the right
fender skirt with the heater and care case
assembly. The upper adjustable bracket and
attaching parts must be assembled loosely
to the core case. At the front, just to the
rear of the battery, use the screws which
held the duct. See view at "B." Do not
tighten. Attach two rear brackets to the
