I have started the body work on the exterior of the car. As you can see in the photos  below, this can be scary for someone (like me) who has never cut away parts of the exterior of their car before with an angle grinder.

The first photo shows the left side area (most MG people call the "dogleg" panel) cutout. I used an angle grinder to accomplish this. The repair panel is a piece made to replace only a portion of the original panel, so it does not fit exactly where you take another panel just like it off.  I placed the repair panel up over the area it was going to replace, and drew a line across the top with a marker. I have a flanging tool, so I had to come down 1/2" from the line I drew to make the line I was going to cut along. The flanging tool places a .40 mm flange in the edge of the panel so that you can attach it to the area it meets, and have the finished connection between the two virtually flat, as opposed to one being overlapped over the other. This worked fairly well except I was not prepared for the repair panel to be flatter than the area it attached to. There was apparently a bend in the original panel that was not put into the replacement piece. To fix this, I used self tapping 1/8" screws and drilled them into the area where the flanged part of the new metal was behind the original panel. This brought the two together with the same degree of bend in both. I took one screw out and a time and mig welded the hole where the one screw was removed while leaving the others in place. This kept the bend in the panel uniform when the welding was completed. The welding part was fun, the angle grinding was not so fun.

The second photo shows a closer view of the area cut out. There was some light rust there, so I cleaned the area with a drill and wire brush attachment. Then I used some rust converter that comes in an aerosol can and converts rust to a primer like black base coat.

The third photo shows the forward most area that the repair panel attaches to. Be careful not to cut too much of this away. The repair panel does not provide enough sheet metal in this area to attach it unless you leave at last as much as I did.

The fourth photo shows the right side dogleg panel. It is rusted out in about the same place that the other side was. I will be repeating this same process again soon on the other side.

The first photo here shows the bashed in front of the left front fender. Lots of work needed there. The other photo shows rust in the threshold of the right side. I have a complete replacement threshold to weld in here after I cut this one out. I have read that you should make sure you have the door fitted correctly before you take the threshold piece out, so that you can weld the new one in with the correct spacing between the door bottom and the threshold. This looks like the most complicated of the body work tasks I have ahead of me.The bumper mounts look rough too! Not sure what bumper I will use yet, so I am leaving that alone for now. I can go back with the original rubber bumper (heavy and unattractive) or I can convert to the chrome bumper found on older MGs, or I can go bumper less with a Sebring front Valence (more modern look).

These are some photos I found on the net of an MGB with the Sebring Valences:

The engine shop suddenly says that my motor may be ready this week. Things are starting to come together.

I decided to tackle the rusty threshold this afternoon. Below are photos of what the car looks like with the outer threshold piece cut off:

I have painted the front rubber bumper to match the car color and I would NOT reccomend that anyone else do this.
The process of getting the bumper to accept paint without bubbling up was painful. This is what it looked like while I was preparing it.

The transmission is back from the shop. It is taller than a stock MGB transmission, so I had to fabricate and weld in a transmission tunnel extention.
There are places that claim to sell these already fabricated, but after six or seven phone calls and a couple of months with nothing received (Not D&D or Towery),
I have my doubts.


This is what the extention looks like installed, but not cleaned up yet:

                                                                           Over View
                                                                        (A liitle dark, sorry)



                                                                            Under View



I also bought another cosmetic touch. An aircraft style billet aluminum gas tank cap. I had to do some hammering and smoothing to get it to fit flush, but it looks great. This is a photo of the cap. I will post a photo of it installled after I get it the way I want it.
