Stair Treads
Landing Tile
Wall Base

Rubber
Choose Color from Color Pallet

Johnsonite Rubber Stair Treads provide years of durable performance with minimal maintenance, yet aesthetically blend the staircase with the surrounding environment. Available in 26 ColorMatch colors and 8 additional colors as well as standard product marbleization. Matching Rubber Stringers and Risers provide a finished look. All Johnsonite Rubber Stair Treads can be specified in Visually Impaired designs with a clearly contrasting minimum 2" abrasive strip insert. They meet Title 24, Section 3306(r) of the Disabled Access Regulations for the State of California. Landing Tile available in Smooth and Diamond Pattern which color coordinate with Rubber Treads to provide a finished installation

Drawing - Stair & Riser

Visually Impaired Stair Tread Standard Grit Tape Colors

Contrasting Grit Tape Color Rubber Stair Tread Colors

Black 59, 58, 55, 48, 29, 28, 13

Brown 80, 60, 49, 45, 42, 34, 33, 22, 19, 03

Gray 92, 88, 86, 85, 40, 20, 18, 15, 06

Tan 63, 47

Yellow or White Special Order

Please make final selection for all colors from actual product samples at Tile 96, Inc, 95-17 Northern Blvd., Jackson Heights, NY 11372. All colors may not be in stock at all times. Consult your salesman for availability and/or minimum order requirements. Custom colors are available on special order. Call 1-718-424-3000 (USA)

Rubber Tile - Rubber Wall Base

Landing Tile - Designed to work with Johnsonite Rubber and Vinyl Stair Treads

Size Pattern Thickness

Smooth (C)
24" x 24"
(610mm x 610mm) Solid or Marbleized .125" (3.175mm)

Diamond (C)
24" x 24"
(610mm x 610mm) Solid or Marbleized .1875" (4.76mm)

Marbleization will vary in mottling and degree from tile to tile

To order us prefix "C" followed by Color Number & Name, Style and Thickness (i.e.: C - 22 Pearl - Smooth Solid - .125"). To order marbleized, add "M" after Color Number (i.e.: 22M with brown, 49M with black/white, 28M with black/white, all other with white veining only. Marbleized tile available in 12" x 12" (305mm x 305mm) smooth on special order basis.

Overall Depth Inches Gauge Tapering Inches Nose Length

Heavy Duty Diamond (C) 13-1/4" (33.66cm) 1/4" (6.35mm) Rd./Sq. 3', 3.5', 4', 4.5', 5', 6' (1' = .3048m)

Heavy Duty Safe-T-Grip (G) 13-1/4" (33.66cm) 1/4" to 1/8" (6.35mm to 3.175mm) Rd./Sq. 3', 3.5', 4', 4.5', 5', 6' (1' = .3048m)

Service Weight Safe-T-Grip (SA) 13-1/4" (33.66cm) 3/16' to 1/8" (4.76mm to 3.175mm) Rd./Sq. 3', 3.5', 4', 4.5', 5', 6' (1' = .3048m)

Service Weight (S) 13-1/4" (33.66cm) 3/16' to 1/8" (4.76mm to 3.175mm) Rd./Sq. 3', 3.5', 4', 4.5', 5', 6' (1' = .3048m)

Sur-Grip (SG) 12-1/4" (33.66cm) 3/16' to 1/8" (4.76mm to 3.175mm) Rd./Sq. 3', 3.5', 4', 4.5', 5', 6' (1' = .3048m)

To order use Tread Style Code followed by Color Number & Name, Length and Round or Square Nose (i.e.: SA -22 Pearl - 6' - Square Nose). To order marbleized, add "M" after Color Number (i.e.: SA 22M). When ordering the above Rubber Stair Treads in Visually Impaired Style add "VI" before tread style (i.e.: VIC - Diamond Tread). Minimum 2" abrasive strip will be in a contrasting color.

STAIR NOSING Installation Drawing

COLOR PALLETE

Size Thickness

Stair Risers (RR) 6" x 4' (15.24cm x 1.22m) .125" (3.175mm)

6" x 100' (15.24cm x 30.48m)** .125" (3.175mm)

7" x 4' (17.78cm x 1.22m) .125" (3.175mm)

7" x 5' (17.78cm x 1.52m) .125" (3.175mm)

7" x 6' (17.78cm x 1.83m) .125" (3.175mm)

7" x 50' (17.78cm x 15.24m)** .125" (3.175mm)

Stringers - Solid (RS) 10" x 6' (25.4cm x 1.83m)** .125" (3.175mm)

Marbleized (RSM) 10" x 6' (25.4cm x 1.83m) .125" (3.175mm)

To order solid color riser use "RR" followed by Color Number, Name, Height, and Length. To order solid color stringer use "RS" followed by Color Number, Name. To order marbleized riser and stringer, add "M" after Color Number. **Not available in marbleized.

Size / Description	Item Number	Retail Price	Discount Price	Image
RUBBER TILE
MEDIUM GRAY #28 SQUARE DESIGN 24" x 24" = 4 sqr feet / each tile 32.00 s.f. / 8 pcs / BOX LOT: OVERRUN	R-FLEX 24X24 2	$ 8.75 PER SQUARE FOOT every day - 1st	$ 2.40 PER SQUARE FOOT limited special sale - 2nds
