- Make:
Acura
- Model:
Integra GS-R
- Power-train:
Transverse front engine/front-wheel drive with equal-length half shafts
- Alternator:
12V, 90 amp max
- Battery:
12 V, maintenance-free
- Engine Block:
Aluminum alloy with cast-iron cylinder liners
- Cylinder Head:
Aluminum alloy
- Emission Control:
3-way catalytic converter
- Engine Type:
1.8-liter, 4-cylinder, 16-valve, DOHC with Variable Valve Timing and Lift Electronic Control (VTEC) system
- Engine Code:
B18C1
- Horsepower, SAE net:
170 hp @ 7600 rpm
- Torque, SAE net:
128 lbs-ft (17.7 kg-m) @ 6200 rpm
- VTEC Engagement:
4400 rpm
- Redline:
8100 rpm
- Fuel Cutoff:
8200 rpm
- Bore & Stroke:
3.19 in x 3.43 in (81 mm x 87.2 mm)
- Connecting Rod Length:
3.19" x 3.43" (81mm x 87.2 mm)
- Displacement:
110 cu in (1797 cc)
- Compression Ratio:
10.0:1
- Induction System:
Programmed Fuel Injection (PGM-FI) with dual-stage intake manifold
- Valve-train:
4 valves per cylinder, belt-driven, dual overhead camshafts with Variable Valve Timing and Lift Electronic Control (VTEC) system
- Ignition System:
Electronic direct ignition with knock sensor
- Transmisson:
5-Speed Manual (Standard)
Gears Ratios (:1) Rpm Mph
1st 3.230 8000 rpm 38 mph
2nd 1.900 8000 rpm 65 mph
3rd 1.360 8000 rpm 91 mph
4th 1.034 8000 rpm 120 mph
5th 0.787 6720 rpm 130 mph
Reverse 3.000
Final Drive 4.400
- Body Type:
All-steel unit body
- Shock Absorbers:
Gas-pressurized, front and rear
- Steering Type:
Rotary-valve, variable power-assisted, rack-and-pinion
- Steering Wheel Turns, lock-to-lock:
2.98
- Turning Circle, curb-to-curb:
34.8 ft (10.6 m)
- Braking System:
Dual-diagonal, power-assisted, 4-wheel disc brakes
- Parking Brake:
Rear, mechanical
- Front Discs:
Ventilated, 10.3 in (262 mm) diameter
- Rear Discs:
Solid, 9.4 in (239 mm) diameter
- Anti-Lock Braking System:
GS-R: Acura-designed Anti-Lock Braking System (ABS) with 4 wheel-speed sensors and electronic/hydraulic control unit
- Front Suspension:
Independent double-wishbone with coil springs and stabilizer bar, 0.94 in (24.0 mm)
- Rear Suspension:
Independent double-wishbone with coil springs and stabilizer bar, 0.55 in (14.0 mm) diameter
- Wheels:
6.0 JJ x 15 cast-aluminum alloy
- Tire Size:
P195/55 R15
- EPA Estimated Mileage, City/Highway:
5-speed: 25/31
- Fuel Tank Approximately:
13.2 U.S. gallons (50 liters)
