THE IMAGING SOURCE CCD ASTRONOMY CAMERAS
THE IMAGING SOURCE DMK21AU04 CAMERA USB VERSION
The DMK21AU04.AS CCD Imaging Camera by The Imaging Source is the best value for money planetary camera available.

Specifications and sample images can be seen on the following page:
http://www.astronomycameras.com/en/products/

The Camera includes 1.25" Adaptor and USB Cable

The new USB Version of the DMK21AU04.AS is now shipped with the 1.25" Telescope Adaptor and also 5m USB Cable.
We are now able to offer the USB DMK21F04.AS with Adaptor and USB Cable for $445AUD

FireWire is useful if you have more than one item running FireWire on your computer, since FireWire is faster than USB.
The FireWire Cameras are listed below the USB models.

ORDER CODE:	DMK 21AU04.AS
TYPE: Mono
IR CUT FILTER:	No
RESOLUTION:	640 x 480
CCD CHIP SIZE:	1/4"
FRAMES PER SECOND:	60
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$445AUD
THE IMAGING SOURCE WEB SITE

ORDER CODE:	DMK 31AU03.AS
TYPE: Mono
IR CUT FILTER:	No
RESOLUTION:	1024 X 768
CCD CHIP SIZE:	1/3"
FRAMES PER SECOND:	30
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$865AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DMK 41AU02.AS
TYPE: Mono
IR CUT FILTER:	No
RESOLUTION:	1280 X 960
CCD CHIP SIZE:	1/2"
FRAMES PER SECOND:	15
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$1088AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DFK 21AU04.AS
TYPE: Colour
IR CUT FILTER:	Yes
RESOLUTION:	640 X 480
CCD CHIP SIZE:	1/4"
FRAMES PER SECOND:	60
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$438AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DFK 31AU03.AS
TYPE: Colour
IR CUT FILTER:	Yes
RESOLUTION:	1024 X 768
CCD CHIP SIZE:	1/3"
FRAMES PER SECOND:	30
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$865AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DFK 41AU02.AS
TYPE: Colour
IR CUT FILTER:	Yes
RESOLUTION:	1280 X 960
CCD CHIP SIZE:	1/2"
FRAMES PER SECOND:	15
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$1088AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DBK 21AU04.AS
TYPE: Colour
IR CUT FILTER:	No
RESOLUTION:	640 X 480
CCD CHIP SIZE:	1/4"
FRAMES PER SECOND:	60
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$438AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DBK 31AU03.AS
TYPE: Colour
IR CUT FILTER:	No
RESOLUTION:	640 X 480
CCD CHIP SIZE:	1/4"
FRAMES PER SECOND:	60
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$865AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DMK 41AU02.AS
TYPE: Colour
IR CUT FILTER:	No
RESOLUTION:	1280 X 960
CCD CHIP SIZE:	1/2"
FRAMES PER SECOND:	15
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$1088AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DMK 21AU04.AS
TYPE: Mono
IR CUT FILTER:	No
RESOLUTION:	640 x 480
CCD CHIP SIZE:	1/4"
FRAMES PER SECOND:	60
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$445AUD
THE IMAGING SOURCE WEB SITE


THE OBSERVERS FILTER WHEEL - $199AUD
ASTRO ENGINEERING
The expert observer’s way to change filters with any 1.25” eyepiece.

The Observers filter wheel has a five-position caddy that allows five separate 1.25” filters to be threaded into position and rotated in
front of a fitted eyepiece for rapid selection. See planetary detail pop into view with the best filter thanks to fuss-free filter selection at
the flick of a finger. Vary the magnification with a quick eyepiece change - no need to fiddle with filters in the dark! Perfect for planetary
and lunar observers. The selection of filters in the wheel can be changed at the telescope in seconds without disassembling of the filter
wheel casing.

Here are just some of the great features of the Observer’s Filter Wheel:
• Ultra-thin 20mm body thickness.
Works with Meade (ETX, LX90, LX200) and Celestron Maks and SCTs.
• All five filter positions fully threaded to accept standard 1.25” filters
• 1.25” nosepiece (chromed brass) also threaded for filters
(and AC555 Magni-Max use)
• Tactile click-stop for each filter position.
• 95% aluminium construction. CNC manufactured in the UK to the highest standards
• Filters all fully enclosed - supplied with anti-dewing cover.
• Light-weight construction: less than 280grams (with four typical filters fitted).

Filter wheel and other critical components black anodized finish, main casing and filter cover finished in black resin powder coating.

Please note: this product is supplied without filters.

























2458350 Baader RGB IR CCD Filter Set $180AUD
Let us know if you want the Filter Transmissions Graphs.


THE IMAGING SOURCE FIREWIRE VERSION CAMERAS
FireWire is useful if you have more than one item running FireWire on your computer, since FireWire is faster than USB.

ORDER CODE:	DMK 31AF03.AS
TYPE: Mono
IR CUT FILTER:	No
RESOLUTION:	1024 X 768
CCD CHIP SIZE:	1/3"
FRAMES PER SECOND:	30
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$865AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DMK 41AF02.AS
TYPE: Mono
IR CUT FILTER:	No
RESOLUTION:	1280 X 960
CCD CHIP SIZE:	1/2"
FRAMES PER SECOND:	15
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$1088AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DFK 21AF04.AS
TYPE: Colour
IR CUT FILTER:	Yes
RESOLUTION:	640 X 480
CCD CHIP SIZE:	1/4"
FRAMES PER SECOND:	60
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$438AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DFK 31AF03.AS
TYPE: Colour
IR CUT FILTER:	Yes
RESOLUTION:	1024 X 768
CCD CHIP SIZE:	1/3"
FRAMES PER SECOND:	30
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$865AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DFK 41AF02.AS
TYPE: Colour
IR CUT FILTER:	Yes
RESOLUTION:	1280 X 960
CCD CHIP SIZE:	1/2"
FRAMES PER SECOND:	15
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$1088AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DBK 21AF04.AS
TYPE: Colour
IR CUT FILTER:	No
RESOLUTION:	640 X 480
CCD CHIP SIZE:	1/4"
FRAMES PER SECOND:	60
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$438AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DBK 31AF03.AS
TYPE: Colour
IR CUT FILTER:	No
RESOLUTION:	640 X 480
CCD CHIP SIZE:	1/4"
FRAMES PER SECOND:	60
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$865AUD
THE IMAGING SOURCE WEB SITE


ORDER CODE:	DMK 41AF02.AS
TYPE: Colour
IR CUT FILTER:	No
RESOLUTION:	1280 X 960
CCD CHIP SIZE:	1/2"
FRAMES PER SECOND:	15
MAXIMUM EXPOSURE:	60 mins.
PRICE:	$1088AUD
THE IMAGING SOURCE WEB SITE


THE OBSERVERS FILTER WHEEL - $199AUD
ASTRO ENGINEERING
The expert observer’s way to change filters with any 1.25” eyepiece.

The Observers filter wheel has a five-position caddy that allows five separate 1.25” filters to be threaded into position and rotated in
front of a fitted eyepiece for rapid selection. See planetary detail pop into view with the best filter thanks to fuss-free filter selection at
the flick of a finger. Vary the magnification with a quick eyepiece change - no need to fiddle with filters in the dark! Perfect for planetary
and lunar observers. The selection of filters in the wheel can be changed at the telescope in seconds without disassembling of the filter
wheel casing.

Here are just some of the great features of the Observer’s Filter Wheel:
• Ultra-thin 20mm body thickness.
Works with Meade (ETX, LX90, LX200) and Celestron Maks and SCTs.
• All five filter positions fully threaded to accept standard 1.25” filters
• 1.25” nosepiece (chromed brass) also threaded for filters
(and AC555 Magni-Max use)
• Tactile click-stop for each filter position.
• 95% aluminium construction. CNC manufactured in the UK to the highest standards
• Filters all fully enclosed - supplied with anti-dewing cover.
• Light-weight construction: less than 280grams (with four typical filters fitted).

Filter wheel and other critical components black anodized finish, main casing and filter cover finished in black resin powder coating.

Please note: this product is supplied without filters.

























2458350 Baader RGB IR CCD Filter Set $180AUD
Let us know if you want the Filter Transmission Graphs.
