Engine Type --- 329cc Air Cooled OHV Dry-Sump Longitudinally Mounted Single Cylinder Four-Stroke
Bore and Stroke --- 78.5mm x 68mm
Carburetion --- 32mm CV
Ignition --- CD with Electronic Advance
Starter --- Electric with Auxiliary Recoil
Transmission --- Fully Automatic Hydromechanical, Continuously Variable, with Electronic Controls
Driveline --- Direct Front and Rear Driveshafts with Limited-Slip Front Differential
Front Suspension --- Independent Double-Wishbone; 5.9 Inch Travel
Rear Suspension --- Swingarm with Single Shock; 5.9 Inch Travel
Front Brakes --- Triple-Sealed Dual Hydraulic Drum
Rear Brake --- Sealed Mechanical Drum
Front Tires --- 24 x 8-12
Rear Tires --- 25 x 11-10
Length --- 78.1 Inches
Width --- 45 Inches
Height --- 44.1 Inches
Wheelbase --- 45 Inches
Seat Height --- 32 Inches
Ground Clearance --- 7.3 Inches
Turning Radius --- 8.5 Feet
Dry Weight --- 498 Pounds
Fuel Capacity --- 3.4 gallons, Including .8 Gallon Reserve
Available Colors --- Olive, Orange, Redbr>
Model ID --- TRX350TM
MSRP: $4399
