DEFINITION OF THE PROCESS PLANT

A Soap manufacturing plant is to be set up at Kalurghat heavy industrial area in Chittagong, having a production Capacity of 40 tons of 86% Soap (Salt of higher fatty acid of sodium or potassium) on a summer day ( dry bulb temp. 35oC & wet bulb temp.25oC) including all off sites, auxiliaries, utilities and supporting facilities using Tallow and palm stearin as feed stock.

There will be 330 stream days a year and the corresponding production of Toilet Soap will be 13200 metric tons for the plant.

 The plant will also produce almost 3.6 metric tons of Glycerin per day which is essential ingredients  in pharmaceutical industries all over the world.

The composition of the product:

Component Wt%
Soap(Na-Salt) 86
Moisture 14

The composition of the raw materials is as follows:

Component Wt%
Palm Sterene 61.54
Coconut Oil 15.38
NaOH(@ 47% Conc.) 23.08

Selection of the process and process description :                        Top

There are three major types of Saponification  processes for production of Soap from fatty acid of higher molecular weight.

The Saponification processes are  as follows:

1.     Full boiled Kettle process,

2.     Cold process saponification,

3.     Semi boiled process.

1.     Full boiled Kettle process:

In this process pan are circular or square in cross section, but taper to cone at the bottom and are generally lagged to conserve heat. Open steam coils in the cone section supply heat and agitation. Closed steam coils may also be present

 to supply heat without adding condensed steam. The bottom layer in any stages   of the boiling procedure is removed from pipelines. Similarly, the upper layer is removed through an adjustable swing pipe located part way down the kettle.

This process supply completely saponified neutral soap containing ca 30 wt% water, a composition which, when hot, can be pumped to various finishing operations. The soap is washed free of soluble colored and odorous impurities and in subsequent processes is separated  as far as possible from Glycerol.



2.     Cold process saponification:

This is the simplest of the batch saponification processes and requires a minumum of equipment. Since neither lyes nor nigre are separated, the glycol and impurities from the fats remain in the soap. The fat charge is simply melted in a vessel equipped with a mechanical stirrer, and the calculated amount of caustic soda solution is added with vigorous stirring. After emulsification and thickening, the mass is poured into frames where saponification is completed during cooling and saponification . The side of the frame are then removed, and the soap slab is cut into bars.



3.     Semi boiled process:

This is similar to the cold process, but a higher  temperature is used to speed saponification and permit adjustment of the alkali content before framing. The fat charge and alkali (which may be caustic potash for soft soap) are thoroughly mixed at 70 – 80oC until the soap becomes smooth. Just prior to framing the soap may be perfumed and small amounts of sodium silicate or other builders may be added to laundry soap and free sand pumices etc. to abrasive hard soap.



From the above discussion it is clear that the Full boiled kettle process is more feasible then other process for commercial production of Toilet Soap. Much of the world’s  soap production still begins in open steel kettle or pans capable of processing batches of 1 – 2000 Kg soap.



So full boiled kettle process with some adopted modification has been chosen for Toilet Soap manufacturing.





                                Process description:

Introduction:

The plant has the capacity of 40 metric tons per day of  Toilet Soap ( as 86% Na- Soap) by a no. of batch operations based on saponification process.
The process consists of following sections:

1.     Crude Soap manufacturing section – PAN room,

2.     Glycerin recovery and purification section – which is a by-product of Soap manufacturing.

3.     Soap finishing and packing section.



Description:



►► Crude soap production section:



i.                    Oil weighting, blending and Bleaching:

First oil is weighted and blended in an open tank prior to bleaching. Vacuum bleaching is done here at around 5 mm HgP Vacuum. Moisture is freed here form oil so that oxidation can not be happened here in saponification operation. Because oxide will cause pyrolysis of the oil. Activated Earth is added here as a bleaching agent.



ii.                 Saponification :



Main feed stock Tallow, palm stearin is charged in a Kettle type pan and Caustic soda is also added with is for saponification reaction to take place.

It is extremely slow process so heat is supplied here in the form of saturated steam at about 3 Bar (gauge) to boiling up the reactants involved in the PAN eractor (Kettle). Boiling time is about one to three Hrs depending up on the load

Crude Soap obtained from here is about 54% TFM

    iii     Washing (DPU):

All materials from the kettle is charged inclined open coutainer where brine solution and niger is flown counter clock wise with respect to product from Saponifier. This section separates Soap from the mixture and Glycerin is separated here.

iv.               Batch fitting and settling :

Crude Soap and Niger solution  thus obtained  from washing tank is charged into a batch fitting and settling tank. Here three additives are added:

a.     Caustic soda,

b.    Water,

c.     Brine solution.

Electrolytic parts are taken by electrolytic additives and soap is separated  and floated on the Niger solution due to density difference.

v.                 Soap base cleansing:

This  is actually a settling tank for soap. Soap is settled according to three layers:

a.     Aerated Soap ( 1 – 1 ½  feet thick layer  ) ,

b.    Neat Soap ( About 8 feet thick layer),

c.     High electrolytic Soap ( 1 – 1 ½  feet thick layer ),

      Remainder section of the tank consists of settled Niger. Time required is about

      36 to 38 hrs for each batch operation.

       However Neat soap is our keen interest for further treatment.

vi.               Soap Drying :

For drying purpose Soap is first heated in heat exchangers . Tow 1 – 2 exchanger is connected in series. Where Sat. steam is used as heating medium. Here Soap is heated up to 140oC   for final Drying section.

Exit from exchanger in charged into a Screw type dryer with a nozzle of about 32 MM size. Soap is flown from top to bottom and is scraped by a scraper inclined about 270o angle. Latent heat of vaporization is supplied by hot Soap (140oC) and dried soap Soap thus obtained is about 40oC.

vii            Stock pan and SFD:

Dried Soap is than charged batch wise in  mixer where various additives and odouring  substances are added in various proportions  to produce finished Soap.

►► Glycerin Production section:

i           First treatment :

Neutral lye  after lye neutralization is charged into first treatment tank where three additives are added for its treatment:

a.      FeCl3,

b.     HCl,

c.     Polyelectrolyte.

FeCl3 is added to convert soap into ferric Soap,

HCl is added to neutralize the basic solution,

Polyelectrolyte is added for coagulation of ferric soap to remove it from the Glycerin part.

ii.          Filter press:

Plate and frame type filter press is used consisting of 32 plates. It removes sludge from glycerin solution.

iii.                Second treatment:

Caustic soda is added to convert FeCl3 into Fe(OH)3 to precipitate out from the glycerin solution.

iv.               Filter press:

Plate and frame type filter press is used consisting of 32 plates. It removes sludge from glycerin solution.

v.                 Double effect Evaporator:

A double effect evaporator is used to concentrate Glycerin solution from 12% to 30% (w/w). Natural circulation vertical tube calendria type evaporator is used for evaporation. 25 inch vacuum is applied in the last stage to boiling up solution at low temperature. Barometric condenser is used for condensation of vapor and steam ejector  is used to create vacuum at  desired level.

vi          Finisher:

      An independent single effect evaporator is used after double effect evaporator      to concentrate Glycerin from 30% to 84% . Vacuum is applied here is about 28       inch HgP and mechanism is the same as mentioned above.

      vii        Still:

84% saturated Glycerin solution is fed into a packed bed distillation column. Here vacuum is applied at about 5 mm HgP(abs). At bottom after reboiler we get 95% pure Glycerin at about 154oC. At top water (98.8%) is removed after condensation by a series of condenser consists of air cooled and batometric condenser .

     vii        Weighting, Drum Filling and ware housing:

About 95 to 98% Glycerin thus obtained is drummed in containers to supply in the near by pharmaceutical industries.

Design basis                                   Top



Design basis is the conditions in existence with which to design the project. These are the boundary conditions for the project. The following items should be included in design basis:

1.Geological data:

a) Load bearing capacity of the soil: 107 ton/m2

           Soil type:              normal

          Win content:      medium

           PH:  8

b) Seismic condition

    Seismic coefficient for seismic load: 0.1

2. Climatic condition:

a) Design condition for equipment or capacity:

1. Cooling tower:

Maximum wet bulb temperature: 30o c

Maximum dry bulb temperature: 35oc

II. Process equipment:

Maximum dry bulb temperature in summer: 35oc

Relative humidity: 80%

Maximum wet bulb temperature in winter: 8oc

b) Design condition for building

HVAC:

Summer:

Maximum dry bulb temperature: 35oc

Maximum wet bulb temperature: 30oc

Winter

Maximum dry bulb temperature: 8oc

c) Meteorological conditions:

I. Ambient temperature:

Maximum:   36.4oc

Average daily maximum: 32oc

Average monthly maximum: 30oc

Average temperature: 27oc

Average daily minimum: 15oc

Average monthly minimum: 20oc

Minimum temperature        :8oc

 II. Humidity

Averages relative humidity: 70%

III.   Rainfall

Average annual rainfall: 2734 mm

Maximum monthly rainfall: 1527 mm

Maximum daily rainfall: 405 mm

Maximum hourly rainfall: 60 mm

Maximum intensity: 108 mm/hr

(Mm/hr in a 15 minutes period)

Design intensity: 100 mm/hr

IV. Barometric pressure:

Minimum pressure at sea level: 750 mm Hg

V. Wind

a) Direction of prevailing wind at site is from south-east during monsoon  (from June to September)

b) Design wind velocity: 68m/sec (150 miles/hr)

c) Design wind loading at each elevation

Elevation  (m) Design wind load (kg/m2 )
H<10 286
10<H<20 331
20<H<30 364
30<H<50 409



3.Utility condition

I. Steam

Saturated steam as heating medium and as driving fluid

Maximum pressure: 3 kg (abs)

a) Water

I.Portable water:

As per the requirements of the US public Health service or WHO regarding bacteriological, physical and chemical characteristics should be fulfilled

II. Demineralization water

Source:

Demin unit

Quality:  ca      less than 0.01 wt ppm

               Mg    less than 0.01 wt ppm

               Fe      less than 0.5 wt ppm

Specific resistance: More than 1*105

c) Electric power

Item Voltage(volt) Phase Frequency(Hz)
Purchase from PDB 33000 3 50
Rectifier Supply 11000 2 50
Instruments 110 1 50
Motor 400 3 50
General lighting 220 1 50
Street lighting 220 1 50
Welding receptacle 400 3 50
Transformer 1100-400/200 3 50

 d) Process Chemicals

Component:

Caustic soda Water Brine
HCl Polyelectrolyte. FeCl3

  4.     Raw material:

                                 Component                         Wt%

                                       Palm Sterene                                    61.54

                                       Coconut Oil                                      15.38

                                       NaOH(47% Conc)                             23.08

EQUIPMENT LIST:                                                                                Top

 Item no. Service Quantity Type
P-101 NaOH Feed Pump 1 Centrifugal
P-102 Coconut oil delivery pump 1 Centrifugal
P-103 Oil delivery pump 1 Centrifugal
P-104 Oil delivery pump 1 Centrifugal
P-105 Boiler water feed pump 1 Centrifugal
P-106 Demoisturizer feed pump 2 Centrifugal
P-107 Bleacher tank feed pump 2 Centrifugal
P-108 Filter press feed pump 2 Centrifugal
P-109 Saponifier pan feed pump 2 Centrifugal
P-110 Crude soap delivery pump 1 Centrifugal
P-111 Spent Lye feed pump 1 Centrifugal
P-112 Divided pan uint delivery pump 1 Centrifugal
P-113 Niger feed pump 1 Centrifugal
P-114 Soap Base cleansing delivery pump 1 Centrifugal
P-115 Dry Saop pumping 1 Gear Pump
P-201 First filter press feed pump 1 Centrifugal
P-202 First filterate press pump 1 Centrifugal
P-203 Second filterate press feed pump 1 Centrifugal
P-204 Evaporator feed pump 1 Centrifugal
P-205 Finisher feed pump 1 Centrifugal
P-206 Centrifuge feed pump 1 Centrifugal
P-207 Still feed pump 1 Centrifugal
HE-101 1st Soap Heater 1 Shell and Tube
HE-102  2nd Soap Heater 1 Shell and tube
DA-101 Soap dryer 1 Rotary vacuum
EV-201 First effect body 1 Natural circulation
EV-202 Finisher 1 Natural circulation
D-201 Packed bed distillation column 1
B-101 Boiler 1 Gas Heated Boiler
FL-101 Filteration 2 Plate and Frame
FL-201 Filteration 1 Plate and Frame
EJ-201 Vacuum 1 Single stage
EJ-202 Vacuum 1 Single stage
CE-201 Solid Separation 1  Cyclone
VE-101 NaOH Storage tank 1 Vertical Cylindrical
VE-102 Coconut Oil Storage tank 1 Vertical Cylindrical
VE-103 Palm Oil Storage tank 1 Vertical Cylindrical
VE-104 Oil Storage tank 1 Vertical Cylindrical
VE-105 Water Storage tank 1 Vertical Cylindrical
VE-106 Blender 2 Vertical Cylindrical
VE-107 Demoisturizer tank 2 Vertical Cylindrical
VE-108 Blender tank 3 Vertical Cylindrical
VE-109 Filtrate storage tank 2 Vertical Cylindrical
VE-110  Saponifier pan 4 Vertical Cubic
VE-111 Divided pan unit 2 Rectangular
VE-112 Batch fitting and settling tank 2 Vertical Cubic
VE-201 First treatment tank 1 Vertical Cylindrical
VE-202 Filtrated storage tank 1 Vertical Cylindrical
VE-203 Second treatment tank 1 Vertical Cylindrical
VE-204 Filtrate storage tank 1 Vertical Cylindrical
VE-205 Brine Preparation tank 1 Vertical Cylindrical
