Bore and Stroke |
60.0 x 54mm (2.36 x 2.12in |
| Compression Ratio | 9.5:1 |
| Displacement | 305cc |
| Contact Breaker Gap | 0.3~0.4mm (0.12~0.16in.) |
| Spark Plug Gap | 0.6~0.7mm (0.035in.) |
| Valve Tappet Clearance | Intake 0.1mm (0.004in.) Exhaust 0.1mm (0.004in.) |
| Spark Plug Type | C7HW or C10H |
| Engine Oil | 1.2 liter (0.46gal.) |
| Fuel Tank | 14 liter (3.7gal.) |
| General Purpose | SAE 10W-30 |
| Above 50 deg F. | SAE 20W-40 |
| Front | 2.75-18 |
| Rear | 3.00-18 |
| Cold Tire Pressure - Front | 26 lb. Up to 200 lb. Load |
| Cold Tire Pressure - Rear | 28 lb. Up to Capacity Load 32 lb. Up to Capacity Load |
| Vehicle Weight | 350 lb. |
| Clutch Lever Free Play | 2-3cm. (.75-1.25in.) |
| Idle Speed | 1200 RPM |
| Chain Deflection | .75in. |
