SUBSTRATE

Cold Rolled Steel 275Mpa to 550Mpa

COLOR COATING

Double-baked epoxy primer and high-grade polyester finish coat that meet PNS and JIS requirements. Also available in Galvalume substrate.

SALT SPRAY TEST RATING

Class 1000 hours (passed 1000 hours of continuous exposure as per PNS 201:1990) for Philmetal Profiles.

AVAILABLE THICKNESS

0.30mm to 0.80mm

LENGTH

Longspan

EFFECTIVE WIDTH

Ranges from 0.76m to 1.07m

MINIMUM ROOF SLOPE

3 degrees ( 1 in 20 )

APPLICATION

Roofing and Sidings
