An introduction to Finite Element Analysis will be conducted at the University of Akron.

A simple, basic approach to the finite element method will be taught, using classroom theory and hands-on approach using the ALGOR finite element system. The instructor is John Stearns, Ph.D. Dr Stearns is a senior development engineer at the Goodyear Tire and Rubber Company and has an extensive background in theoretical and practical applications in FEA. The 5 hour seminar will focus on solving linear static stress situations and basic heat transfer (if time allows). Refreshments will be provided.

1. Finite element analysis (FEA) theory for linear analysis
2. Proper FEA modeling: elements and nodes
3. Unit system screen
4. Using the Material Library Manager
5. Navigating the ALGOR interface
6. Using Superdraw III to build or import models
7. Static stress analysis using:
   • 2-D elements for plane stress and axisymmetric models
   • 3-D truss elements for space structures
   • 3-D plate elements
   • 3-D beam elements for structures, understanding beam element orientation and properties
   • 3-D solid FEA models using bricks, tetrahedral or a hybrid approach
   • Boundary elements and symmetry conditions
   • Gap/cable elements
8. Postprocessing interpretation
9. Displacements
10. Stresses
11. Mesh convergence testing
