KING MAJOR Model
New model that enables the dynamic control of both the Timbre and Volume by means of the bellowsRevolutionary New Solid State Contact System, eliminates all those annoying noisey and false contact problems, frequently caused by wear and dirt when a traditional contact system is employed. Featuring all the outstanding characteristics of the above KING model plus the inclusion of the following functions:
Possibility to memorize the performaces with different MIDI channels
Each performace can memorize DUE POLYPHONIC PRESETS on the right hand, one PRESET for the bass, one PRESET for the chords, PROGRAM CHANGE, OTTAVE, VOLUME and the DIFFERENT MIDI CHANNEL of various sections
Possibility to recall Preferred Performances from 25 banks memorized in 'Real Time'
PITCH BEND function (optional)
KING Model (External)
Same characteristics as internal version but with external Control Box?Power Supply
MIDI BASS
Interface for use with the left hand
Models PRINCE and MIDI BASS are both available for use with Diatonic Instruments
For use with all MIDI Interfaces to enable 'no cables' freedom of movement. Small size Transmitter/Receiver units
Transmitter
Operates on VHF Frequency Band from 170 to 210 Mhz on 5 quartzd channels
9V battery operation with 'low battery' indicator
Battery duration >5 hours
Receiver
Quartz controlled tuning
Squelch control for standby noise elimination
Squelched noise level:> 110 B
12V 150mA Power Suppy
Keyboards
Right Hand - 87 buttons with dynamics
Left Hand - 120 buttons
Programmable Performances
Memorizes 128 Performances
Each performance memorizes: MIDI Channels, Octave for each section, Start/Stop
Each performance memorizes: Tempo, Program Change, Cointrol Change, Transpose, Dynamics and Volumes
MIDI In, MIDI Out (16 Control Channels), MIDI THRU
Pitch and Modulation Wheels
Illuminated L.C.D.
Dimension (cm): 96(L) x 21(W) x 12(H)
The solution for musicians used to the chromatic accordion techniques who want to explore the world of keyboards and MIDI. A GENERAL MIDI standard instrument that transmits up to 2,097,152 sounds in GS-GM on all MIDI channels by means of the CCO, CC32 command.
Keyboards
Right hand - 87 buttons with dynamics
Left hand - 120 buttons
Programmable Performances
Memorizes 128 Performances
Each performance memorizes: MIDI Channels, Octave for each section, Start/STop. Tempo, Program Change, Cofntrol Change, Transpose, Dynamics and Volumes.
MIDI In, MIDI Out (16 Control Channels), MIDI THRU
Pitch and Modulation Wheels
Illuminated L.C.D.
Dimensions (cm): 96(L) x 21(W) x 12(H)
ORLA
SM600 Orchestra Modules - 104 Polyphony
Sound Source- High Quality Sampled Sounds
Poly 1 Section - 168 Sampled Sounds Available, 60 sounds available on pannel
Poly 2 Section - 168 Sampled Sounds Available, 48 sounds available on pannel
Solo Section - Chorus, Sustain, Octave, User, D.C.S. Section Control Volume, 168 Sampled Sounds Available, 16 sounds available on pannel
Bass Section - Portamento, Poly/Mono, Octave, User, Volume, 168 Sampled Sounds Available, 16 sounds available on pannel
Conductor - Sustain, Octave, User, Volume, Poly1, Poly2 Right, Solo, Poly 2 Left, DCS
Rhythm Section60 Styles with 3 Variations (5 parts arrangements), 16 User Styles
S.M.F. Disk RecorderMFC/OFC, Auto Bass, Auto Chors, Memory, Split, Intro/Ending, Fade, Fill 1/2, Auto Start, Start/STop, Drum Volume, Acc.1 Volume, Acc.2 Volume, Acc.3 Volume, Play/STop, Record, Pause, melody On/Off, Scroll Up/Down
One Touch Reg.Rew./FF, Volume, 60 Style Settings
Overall Prets28 User Programs
Programmable Styles - 16 Programmable Styles
Effects - Reverb: 12 Types of Digital Reverb, Organ Motion Effect
Controls - Slow/Fast, Master Volume, Left Volume On/Off, OMC, Set Button
Tuning - Transpose, Pitch
Dynamic - On/Off, 3 selectable dynamic Curves: Hard, Normal, Light
Demo - Demo Songs
Midi - Control Change On/Off, Program Change On/Off, Local Control
Pedals - On/Off, Midi In (2)/Out/Thru, Programmable Pedals
Sockets - L/R Outputs, L/R Inputs
Headphone - Headphone Socket
Weight - 7 Kg.
Size - 40 (W) x 29 (D) x 9 (H) cm.
The solution for musicians used to the chromatic accordion techniques who want to explore the world of keyboards and MIDI. A GENERAL MIDI standard instrument that transmits up to 2,097, 152 sounds in GS-GM on all MIDI channels by means of the CCO, CC32 command.
XM100 Orchestra Module - 32 Polyphony
Sound Source - High Quality Sampled Sounds
Sound 1 Section - 128 Sampled Sounds Available, Volume
Sound 2 Section - 128 Sampled Sounds Available, Volume
Bass Section - 128 Sampled Sounds Available, Volume
Rhythm Section - 64 Styles with 3 Variations (5 parts arrangements), Intro/Ending
One Touch Reg. - Fill 1/2, Auto Start, Start/Stop, Drum Volume, Acc. Volume, 64 Style Settings
Effects - Reverb: 2 Types of Digital Reverb, Chorus
Controls - Master Volume
Tuning - Traspose, Pitch
Midi - Contorl Change On/Off, Program Change On/Off, Local Control
Pedals - On/Off, Midi In (2)/Out/Thru, Programmable Pedals
Sockets - L/R Outputs
Headphone - Headphone Socket
Weight - 2 Kg.
Size - 30 (W) x 22 (D) x --(H) cm.
Real-Time Tone Generator-Arranger for M.I.D.I. Accordions for MIDI Accordions
We will install M.I.D.I. systems in anyone's accordion! Call for prices!
