Wingnut
Having
been a wingnut since I was old enough to crawl out side and look up, and
being fairly well versed in aerodynamics, tool making, modeling, electronics
and the like,
I would like to offer
the following services to you:
1. I would like to develop working
drawings, engineering data, and full construction plans for the aircraft
of your choice.
2. Help
you choose a good aircraft suitable for a flying scale model. Some
aircraft are much better choices than others.
3. Help you design
your own proto type aircraft, with all the engineering data such as
airfoil choice, power plant information, and
images when possible.
The selections at the
top of the page, especially the first two, are excellent choices for scale
models, because first of all, they both have a one piece cantilevered wing.
This simplifies construction, and facilitates access to the interior for
hardware installation. The other two examples, should
be built with separate wing panels so as not to interfere with the scale
cabin lines. That means that the struts must be functional, and although
this is more complicated, it really adds to scale appearance. A good
example of this would be a one eighth scale Lippet Reed Cub. At one
eighth scale, this model would not have to be disassembled for transportation
to the flying site as it's wing span would only be 58". I have carried
that particular model in the back seat of my 68 Camero coupe without taking
the wings off. If for instance, you decide on a J-3 airframe to begin
with, it can easily be modified into a J-5 Super Cruiser, or a PA-18 Super
Cub. The Monocoupe could easily be designed as the 90A radial engine
powered, or the 90AL inline version. Another great choice for a scale
model would be the Lockheed Vega, again because of the one piece cantilevered
wing. The only variations from scale on most of these aircraft might
be the wing area or control surface area. As the size of the model
decreases, so does the wing loading, and unless the surface is decreased,
it would become a kite and not exhibit true flight characteristics.
Here at Friendship Cad, I have a software library that will solve these
problems and aid in realistic designs.
Please contact me at
n1was@hotmail.com and let me know what aircraft you would like to build.
You may want to consider a full scale design,
and I would be happy to help you get started.
We are currently working
on designs for downlink hardware for radio controllers, to supply the pilot
with information about airspeed, fuel and battery state, and an ELT in
case of a fly away.
Suggestions welcomed!
