High Definition Television (HDTV) ___________________________________ HDTV is the biggest breakthrough in broadcasting since color TV. It offers wider pictures with greater detail and the clarity of motion pictures. Compared to standard television (NTSC), the true HDTV image has twice the luminance definition - vertically and horizontally - and is twenty-five percent wider. Standard television aspect ratio is 4:3 (four units wide, three units high) - the HDTV aspect ratio is 16:9. The 16:9 ratio is much closer to the average wide-screen image shown in movie theaters. The biggest difference, and the greatest appeal of HDTV, is its clarity. True HDTV pictures are composed of 1080 active lines (1125 total) whereas current standard television pictures are composed of only 486 active lines (525 total). While it is possible to see the lines that make up standard television pictures, HDTV lines are not at all noticeable. The fine-grained HD picture contains five times more information than does the standard television picture and is accompanied by multi-channel, CD quality sound. The difference in video and sound quality is dramatic. |
General DTV information
Information on ATSC standards
:
www.atsc.org The latest FCC DTV channel allocation tables: www.transmitter.com FCC FAQs on Digital TV : http://www.fcc.gov/oet/faqs/dtvfaqs.html Samsung DTV FAQs page : www.samsungusa.com/dtvguide General DTV information, reviews, antenna tests : www.hdtvexpert.com Antenna Channel Guide (by zipcode) : www.titantv.com Weekend Project : HD Antenna C|Net How To CEA's antenna mapping program : antennaweb.org About TV and FM Antennas - Fundamentals of Antennas A Guide to UHF TV Reception - UHF Reception Guide Broadcast flag - www.mpaa.org/Press/Broadcast_Flag_QA.htm High-bandwidth Digital Content Protection - http://www.digital-cp.com Electronic Freedom Foundation - www.eff.org CBS programming - http://www.cbs.com/info/hdtv ABC programming - http://abc.go.com/site/hdtvfaq.html NBC programming - http://www.nbc.com/nbc/footer/HDTV.shtml WB Programming - http://www.thewb.com/Index/0,7349,,00.html UPN Programming - http://www.upn.com PBS Programming - http://www.pbs.org/digitaltv/dtvsched.htm Fox programming - http://www.fox.com/schedule HDNet programming - http://www.hd.net ESPN HD programming - http://sports.espn.go.com/sports/tvlistings/espnhd/index HBO Programming - www.hbo.com Showtime programming - www.showtimeonline.com Discovery HD programming - http://dhd.discovery.com |
Antenna Selection for Local Broadcast Reception Factors that Determine Signal Reception:
Distance from the transmitters - the closer you are to the transmitters, the stronger the signals will be so a small antenna may be all that's needed. The farther away you are, the weaker the signals will be so a bigger antenna may be more appropriate. Topography - if there are obstructions such as building, hills, and trees between your location and the transmitters, then expect the signals to be blocked or reflected and impact the signal that reaches your antenna. If the blockage is significant, you may not even get any signal at all. For multipath plagued locations, directional antennas are best. Every installation is Unique! Note that above are not hard and fast rules. Every installation is unique, so what works in one installation may not work in another. What works for your neighbor may not work for you. It's a trial and error type exercise for the most part.
What works for one might not work in your situation. So, be open minded and be flexible. Antenna Recommendations Note: Prices listed below are from Yr 2000. Prices might have changed since then. Please check the sources for more updated pricing. Here's a quick run down of recommended OTA antennas:
Don't bother with the Terk models. They are more hype than performance. Rule of thumb for antenna: The larger the antenna the more elements. The more elements the more gain. The more gain the better the reception. This is especially true for fringe installations: the bigger the better, the higher (i.e, rooftop install) the better. Outdoor Installations and HOA Restrictions Unless one of the conditions apply, you should be able to install your antenna outdoors
But to be sensitive to your neighbors and the community, you should at least install the antenna in the least conspicuous location without degrading your signal reception. To learn more about FCC's ruling on outdoor antennas, read these
Other Antenna Needs You may need a rotor if you are near other large metro broadcast centers. The Channel Master CM 9521 rotator with remote control is very good. If the signal is weak at the output end of the antenna, you may need a preamp. The Channel master 7775, 7777 are good. Winegard AP-4700 (16db) is good and so is the higher gain AP-4800. Always always always have a rooftop antenna grounded. The mast should be grounded (#8 or #10 gauge wire) to a ground rod vs. water pipe. Coax line from the antenna should also have a discharge block/lightning arrestor and tied to the ground rod. Aside from being the law, properly grounding the antenna is needed to reduce the risk of damage to persons and property by channeling the bulk of the lightning energy to ground; reduce the risk of fire; meet NEC requirements and local antenna install regulations; and eliminate the possibility of insurance companies denying a claim due to improper grounding or lack thereof. |
